Bosch GLL 3X Crossline Laser Level

Bosch GLL 3X Crossline Laser Level

SKU: 0601063CJ0 Category: Line & Point Lasers

The Bosch GLL 3X Professional is positioned as an advanced entry-level 3-line crossline laser level. It is a simple and easy product which has adequate technical specification and a more competitive pricing. It’s the ideal tool for users doing the basic levelling work in interior area at relatively small job sites!

  • Working Range 15m
  • Soft grip components prevent slipping
  • Projection and leveling accuracy of +/- 0.5mm @ 1m
  • Self leveling function The instrument levels itself in the range of ± 4°
  • Compact – Pocket size for handy usage
  • Easy to Use – Simple & easy interface for various measuring functions
  • Three line laser with a cross beam and one vertical side beam
  • Vivid line visibility and robust design for maximum work efficiency
Description
Key Features of Bosch GLL 3X Professional Laser Level Device
  • The Bosch GLL 3X Professional is positioned as an advanced entry-level 3-line crossline laser level. It is a simple and easy product which has adequate technical specification and a more competitive pricing. It’s the ideal tool for users doing the basic levelling work in interior area at relatively small job sites!
  • The Bosch GLL 3X supports easy handling and accuracy in measurement whilst working. It weighs only 0.5 kg and comes with a compact build which makes it extremely portable. With this premium device you have the ability to work for long hours effortlessly on your home tasks equipped with a Class II 635 Nm laser. Thanks to its working range of 15 m, a levelling accuracy of ±0.5 mm/m and a self-levelling range of ±4˚, Bosch GLL 3X is the ideal hobbyist’s tool.
Functionality
  • Bosch GLL 3X works on an easy to use interface which is literally a one person task. All you need to do is tap on the on/off switch as its operating mode selection and you are good to go.To retrieve results for, front cross line and one side vertical line in 90˚ results tap once, for horizontal line only tap twice, for vertical line only tap thrice and with the fourth press the tool is off.
Battery life
  • Power-driven by four 1.5V LR6 (AA) batteries it has an optimised runtime which is in every hobbyist priority list. You can work with it for long hours without the stress of running out of battery and complete your jobs on time without any obstruction.
Specifications of Bosch GLL 3X Laser Level
Working Range 15m
Levelling Accuracy ±0.5mm/m
Self-levelling range ±4°
Laser diode/class 635 Nm <1 mW/2
Tripod thread size 1/4″
Operating time, max. 15h
Tripod thread yes
Batteries type AA 4 × 1.5 V
Weight 500g
Dimension 97 x 65 x 120 mm
Warranty One Year Warranty
Bosch GLL 3X Scope of delivery:
  • Bosch GLL 3X
  • Carrying Pouch
  • 4 x AA Alkaline Batteries
  • User Manual
Video of Bosch GLL 3X Professional Laser Level
